Trimming press KG 9534.01 250 ton
Machine ID: TRG-250-TP-01
Year1991
Nominal force250 ton
Stroke320 mm
Strokes per minute45
Sold
Inspection, loading, dismantling and export logistics.
Used trimming press KG 9534.01 with 250 ton nominal force. Suitable for trimming operations with stable stroke speed and robust frame.
- Video available (see in gallery).
- We can arrange inspection, dismantling, packaging and international delivery.
- Please mention the machine ID when requesting an offer.
Technical description
KG 9534.01 is a trimming press designed for trimming and finishing operations where repeatable stroke and stable force are required. The press offers a 320 mm slide stroke and up to 45 strokes per minute, making it suitable for productive trimming cycles.
The working area includes an 800 × 800 mm table and 670 × 630 mm slide, with 140 mm adjustment and 390 mm shut height (upper position). A 140 mm bolster plate supports tooling installation.
Technical data
ModelKG 9534.01
TypeTrimming press
Year of manufacture1991
Nominal force250 ton
Slider stroke320 mm
Strokes per minute45
Single strokes frequency (max)24 / min
Shut height (bed to slider, upper)390 mm
Slider adjustment140 mm
Table dimensions800 × 800 mm
Slider dimensions670 × 630 mm
Bolster plate thickness140 mm
Overall dimensions (L × W × H)2500 × 2400 × 4850 mm
Weight18,600 kg
